中空玻璃的密封質量，直接決定了其隔熱、隔音性能和使用壽命。在過去，玻璃合片后的封膠工序長期依賴人工——不僅效率低、勞動強度大，涂膠質量還因人而異。全自動封膠線的出現，用人機界面+伺服控制+自動修角的完整解決方案，將這道工序推向了“一鍵操作、批量交付”的工業化新階段。

The sealing quality of insulating glass directly determines its thermal insulation, sound insulation performance, and service life. In the past, the sealing process after glass lamination relied on manual labor for a long time - not only was it inefficient and labor-intensive, but the quality of the coating also varied from person to person. The emergence of fully automatic sealing lines, with a complete solution of human-machine interface, servo control, and automatic corner trimming, has pushed this process to a new stage of industrialization with "one click operation and batch delivery".

一、使用范圍：面向規模化生產

1、 Scope of use: Targeting large-scale production

全自動封膠線適用于合片后的中空玻璃周邊自動涂膠，是大規模玻璃深加工企業的標配設備。其可加工玻璃非常大尺寸覆蓋2500×4000mm，非常小尺寸300×300mm，玻璃厚度范圍12-56mm，打膠速度達5-40m/min。

The fully automatic sealing line is suitable for automatic coating around the hollow glass after lamination, and is a standard equipment for large-scale glass deep processing enterprises. It can process glass with a maximum size coverage of 2500 × 4000mm, a minimum size of 300 × 300mm, a glass thickness range of 12-56mm, and a glue application speed of 5-40m/min.

該設備支持雙組份密封膠的自動供膠和切換，可配備兩套供膠系統，在聚硫膠和硅酮膠之間一鍵切換。除了標準雙玻中空玻璃，還支持三玻兩腔、四玻三腔等復雜結構的自動涂膠。

This device supports automatic supply and switching of two-component sealant, and can be equipped with two sets of glue supply systems to switch between polysulfide glue and silicone glue with one click. In addition to standard double glass insulated glass, it also supports automatic gluing of complex structures such as three glass two cavity and four glass three cavity.

二、核心優勢：質量、效率與操作的多維度升級

2、 Core advantage: Comprehensive upgrade of quality, efficiency, and operation

全自動封膠線非常直觀的優勢體現在打膠質量的標準化上。設備涂膠后玻璃周邊飽滿無氣線，角部充實，表面平整圓滑，無需人工修角。針對角部處理，部分機型在操作屏上一鍵開啟修角功能，四個角可單獨控制修角次數，配備自動上水修角棉，進一步提升角部美觀度。

The most intuitive advantage of fully automatic sealing line lies in the standardization of adhesive quality. After the equipment is coated with glue, the edges of the glass are full and free of air lines, the corners are full, the surface is smooth and even, and there is no need for manual corner repair. For corner treatment, some models enable the corner trimming function with one click on the operation screen, and the four corners can be individually controlled for the number of corner trimming times. Equipped with automatic water filling corner trimming cotton, it further enhances the beauty of the corners.

在效率層面，伺服控制系統采用國際品牌（如安川），性能穩定，定位合理。同步帶式傳送使玻璃輸送平穩，第三段可預存玻璃，實現了流水作業和在線封膠的連續化生產。

In terms of efficiency, the servo control system adopts international brands (such as Yaskawa), with stable performance and precise positioning. The synchronous belt conveyor ensures smooth glass transportation, and the third section can pre store glass, achieving continuous production of assembly line operation and online sealing.

柔性適應能力是新一代封膠線的突出亮點。面對市場越來越多的大小片（不等片）玻璃需求，通過技術升級和結構改造，設備可完成大小片的涂膠——機頭后置適合鍍膜玻璃（小片在內），機頭前置適合常規玻璃（小片在外），每個邊的參數均可獨立輸入操作界面。通過增加模塊單元，還能實現自動上下片和異形玻璃涂膠。

Flexible adaptability is a prominent feature of the new generation of sealing lines. Faced with the increasing demand for glass of different sizes in the market, through technological upgrades and structural modifications, the equipment can complete the gluing of large and small pieces - the rear of the machine head is suitable for coated glass (small pieces inside), and the front of the machine head is suitable for conventional glass (small pieces outside), and the parameters of each side can be independently input into the operation interface. By adding module units, automatic loading and unloading of sheets and adhesive coating of irregular glass can also be achieved.
